Use (neo)vim terminal in the floating/popup window.

• Features
• Requirements
• Installation
• Get started
  • Commands
  • Options
  • Keymaps
  • Highlights
• Advanced Topics
  • Use with command line tools
  • Use with other plugins
  • How to define more wrappers
  • How to write sources for fuzzy finder plugins
• Wiki
• FAQ
• Breaking changes
• Related projects
• Credits
• License

• Support neovim floatwin and vim8 popupwin
• Manage multiple terminal instances
• Customizable terminal window style
• Switch/preview floating terminal buffers using fuzzy-finder plugins such as denite.nvim or coc.nvim, etc.
• Use with other external command-line tools(ranger, lf, fzf, etc.)
• Autocompletion from within floaterms(require coc.nvim or deoplete.nvim)
• Use as a custom task runner for asynctasks.vim or asyncrun.vim

• Vim or neovim with terminal feature

Run :checkhealth for more info.

• vim-plug

Plug 'voldikss/vim-floaterm'

• dein.nvim

call dein#add('voldikss/vim-floaterm')

Use :FloatermNew to open a terminal window, use :FloatermToggle to hide/reopen that. The filetype of the terminal buffer is floaterm.

If you've opened multiple floaterm instances, they will be attached to a double-circular-linkedlist. Then you can use :FloatermNext or : FloatermPrev to switch between them.

• If ! is given, execute cmd in $SHELL. Try :FloatermNew python and : FloatermNew! python to learn about the difference.
• If execute without cmd, open $SHELL.
• The options is formed as --key[=value], it is used to specify local attributes of a specific floaterm instance. Note that in order to input space, you have to form it as \ followed by space, and \ must be typed as \\
  • cwd working directory that floaterm will be opened at, accept either a path or literal <root> which represents the project root directory
  • name name of the floaterm
  • silent If --silent is given, spawn a floaterm but not open the window, you may toggle it afterwards
  • height see g:floaterm_height
  • width see g:floaterm_width
  • title see g:floaterm_title
  • wintype see g:floaterm_wintype
  • position see g:floaterm_position
  • borderchars see g:floaterm_borderchars
  • autoclose see g:floaterm_autoclose
• Use <TAB> to get completion.
• This command basically shares the consistent behaviors with the builtin :terminal :
  • The special characters(:help cmdline-special) such as % and <cfile> will be auto-expanded, to get standalone characters, use \ followed by the corresponding character(e.g., \%).
  • Note that <bar>(i.e., |) will be seen as an argument of the command, therefore it can not be followed by another Vim command.

For example, the command

:FloatermNew --height=0.6 --width=0.4 --wintype=float --name=floaterm1 --position=topleft --autoclose=2 ranger --cmd="cd ~"

will open a new floating/popup floaterm instance named floaterm1 running ranger --cmd="cd ~" in the topleft corner of the main window.

The following command allows you to compile and run your C code in the floaterm window:

:FloatermNew --autoclose=0 gcc % -o %< && ./%<

• The options is the same as in :FloatermNew (except --silent).
• Use <TAB> to get completion.

• If N is given, toggle the floaterm whose buffer number is N
• If floaterm_name is given, toggle the floaterm instance whose name attribute is floaterm_name. Otherwise create a new floaterm named floaterm_name.
• Use <TAB> to get completion.
• If ! is given, toggle all floaterms

• If N is given, show the floaterm whose buffer number is N
• If floaterm_name is given, show the floaterm named floaterm_name.
• If ! is given, show all floaterms

• If N is given, hide the floaterm whose buffer number is N
• If floaterm_name is given, show the floaterm named floaterm_name.
• If ! is given, hide all floaterms

• If N is given, kill the floaterm whose buffer number is N
• If floaterm_name is given, kill the floaterm instance named floaterm_name.
• If ! is given, kill all floaterms

• If --name=floaterm_name is given, send lines to the floaterm instance whose name is floaterm_name. Otherwise use the current floaterm.
• If cmd is given, it will be sent to floaterm and selected lines will be ignored.
• This command can also be used with a range, i.e., '<,'>:FloatermSend [--name=floaterm_name] to send selected lines to a floaterm.
  • If cmd is given, the selected lines will be ignored.
  • If use this command with a !, i.e., '<,'>:FloatermSend! [--name=floaterm_name] the common white spaces in the beginning of lines will be trimmed while the relative indent between lines will still be kept.
• Use <TAB> to get completion.
• Examples

  :FloatermSend                        " Send current line to the current floaterm (execute the line in the terminal)
  :FloatermSend --name=ft1             " Send current line to the floaterm named ft1
  :FloatermSend ls -la                 " Send `ls -la` to the current floaterm
  :FloatermSend --name=ft1 ls -la      " Send `ls -la` to the floaterm named ft1
  :23FloatermSend ...                  " Send the line 23 to floaterm
  :1,23FloatermSend ...                " Send lines between line 1 and line 23 to floaterm
  :'<,'>FloatermSend ...               " Send lines selected to floaterm(visual block selection are supported)
  :%FloatermSend ...                   " Send the whole buffer to floaterm

Type String. Default: &shell

Type String. Show floaterm info(e.g., 'floaterm: 1/3' implies there are 3 floaterms in total and the current is the first one) at the top left corner of floaterm window.

Default: 'floaterm: $1/$2'($1 and $2 will be substituted by 'the index of the current floaterm' and 'the count of all floaterms' respectively)

Example: 'floaterm($1|$2)'

Type String. 'float'(nvim's floating or vim's popup) by default. Set it to 'normal' if your vim/nvim doesn't support floatwin or popupwin feature.

Type Number (number of columns) or Float (between 0 and 1). If Float, the width is relative to &columns.

Default: 0.6

Type Number (number of lines) or Float (between 0 and 1). If Float, the height is relative to &lines.

Default: 0.6

Type String. The position of the floating window. Available values:

• If wintype is normal: 'top', 'right', 'bottom', 'left'. Default: 'bottom'
• If wintype is float: 'top', 'right', 'bottom', 'left', 'center', 'topleft', 'topright', 'bottomleft', 'bottomright', 'auto'(at the cursor place). Default: 'center'

In addition, there is another option 'random' which allows to pick a random position from above when (re)opening a floaterm window.

Type String. 8 characters of the floating window border (top, right, bottom, left, topleft, topright, botright, botleft).

Default: ─│─│┌┐┘└

Type List of String. Markers used to detect the project root directory for --cwd=<root>

Default: ['.project', '.git', '.hg', '.svn', '.root']

Type String. Command used for opening a file in the outside nvim from within :terminal.

Available: 'edit', 'split', 'vsplit', 'tabe', 'drop'. Default: 'edit'

Type String. Opening strategy for COMMIT_EDITMSG window by running git commit in the floaterm window. Only works in neovim.

Available: 'floaterm'(open gitcommit in the floaterm window), 'split'(recommended), 'vsplit', 'tabe'.

Default: '', which means this is disabled by default(use your own $GIT_EDITOR).

Type Number. Whether to close floaterm window once the job gets finished.

• 0: Always do NOT close floaterm window
• 1: Close window if the job exits normally, otherwise stay it with messages like [Process exited 101]
• 2: Always close floaterm window

Default: 0.

Type Boolean. Whether to enter Terminal-mode after opening a floaterm.

Default: v:true

Type Boolean. Decide whether to hide previous floaterms before switching to or opening a new one.

Default: v:true.

Type Dict. Autocompletion options (The completion from floaterm is synchronous)

Available options:

• shortcut: A string.
• priority: Number between 0-99.
• filetypes: Array of filetype names this source should be triggered by. Available for all filetypes when ommited and for no filetypes when empty
• filter_length: Array of 2 numbers. Candidates whose length is not in the range will be removed.

Default value: {'shortcut': 'floaterm', 'priority': 5, 'filter_length': [5, 20]}

This plugin doesn't supply any default mappings. Here are the configuration examples.

" Configuration example
let g:floaterm_keymap_new    = '<F7>'
let g:floaterm_keymap_prev   = '<F8>'
let g:floaterm_keymap_next   = '<F9>'
let g:floaterm_keymap_toggle = '<F12>'

You can also use other keys as shown below:

let g:floaterm_keymap_new = '<Leader>ft'

All options for the mappings are listed below:

• g:floaterm_keymap_new
• g:floaterm_keymap_prev
• g:floaterm_keymap_next
• g:floaterm_keymap_first
• g:floaterm_keymap_last
• g:floaterm_keymap_hide
• g:floaterm_keymap_show
• g:floaterm_keymap_kill
• g:floaterm_keymap_toggle

Note that the key mappings are set from the plugin/floaterm.vim, so if you are using on-demand loading feature provided by some plugin-managers, the keymap above won't take effect(:help load-plugins). Then you have to define the key bindings by yourself. For example,

nnoremap   <silent>   <F7>    :FloatermNew<CR>
tnoremap   <silent>   <F7>    <C-\><C-n>:FloatermNew<CR>
nnoremap   <silent>   <F8>    :FloatermPrev<CR>
tnoremap   <silent>   <F8>    <C-\><C-n>:FloatermPrev<CR>
nnoremap   <silent>   <F9>    :FloatermNext<CR>
tnoremap   <silent>   <F9>    <C-\><C-n>:FloatermNext<CR>
nnoremap   <silent>   <F12>   :FloatermToggle<CR>
tnoremap   <silent>   <F12>   <C-\><C-n>:FloatermToggle<CR>

There are two highlight-groups to specify the color of floaterm (also the border color if g: floaterm_wintype is 'float') window.

To customize, use hi command together with the colors you prefer.

" Configuration example

" Set floaterm window's background to black
hi Floaterm guibg=black
" Set floating window border line color to cyan, and background to orange
hi FloatermBorder guibg=orange guifg=cyan

Besides, there is a neovim only highlight group which can be used to configure no-current-focused window(:help NormalNC).

" Configuration example

" Set floaterm window background to gray once the cursor moves out from it
hi FloatermNC guibg=gray

The following cases should work both in Vim and NeoVim unless otherwise specifically noted.

Normally if you run vim/nvim somefile.txt within the builtin terminal, you would get another nvim/vim instance running in the subprocess.

Floaterm, which is a builtin script in this plugin, allows you to open files from within : terminal without starting a nested nvim. To archive that, just literally replace vim/nvim with floaterm, i.e., floaterm somefile.txt

❗️Note: This should works both in neovim and vim, but if you are using neovim, make sure neovim-remote has been installed. You can install it via pip:

pip install neovim-remote

P.S. #208 describes how to use gf in the floating terminal window.

See g:floaterm_gitcommit option.

Execute git commit in the terminal window without starting a nested nvim.

❗️Note: neovim only feature. Moreover, it also requires neovim-remote, please install it using pip3 install neovim-remote.

This plugin has implemented a wrapper for fzf command. So it can be used as a tiny fzf plugin.

Try :FloatermNew fzf or even wrap this to a new command like this:

command! FZF FloatermNew fzf

There is also an fff wrapper

Try :FloatermNew fff or define a new command:

command! FFF FloatermNew fff

There is also an nnn wrapper

Try :FloatermNew nnn or define a new command:

command! NNN FloatermNew nnn

There is also an lf wrapper

Try :FloatermNew lf or define a new command:

command! LF FloatermNew lf

This plugin can also be a handy ranger plugin since it also has a ranger wrapper

Try :FloatermNew ranger or define a new command:

command! Ranger FloatermNew ranger

There is also a vifm wrapper

Try :FloatermNew vifm or define a new command:

command! Vifm FloatermNew vifm

Furthermore, you can also use other command-line programs, such as lazygit, htop, ncdu, etc.

Use lazygit for instance:

Use :FloatermNew python to open a python shell. After that you can use : FloatermSend to send lines to the Python interactive shell.

This can also work for other languages which have interactive shells, such as lua, node, etc.

Use vim-clap to switch/preview floating terminal buffers.

Try :Clap floaterm

Use denite to switch/preview/open floating terminal buffers.

Try :Denite floaterm

Use CocList to switch/preview/open floating terminal buffers.

Install coc-floaterm and try :CocList floaterm

Install fzf-floaterm and try :Floaterms

Install LeaderF-floaterm and try :Leaderf floaterm

This plugin can be a runner for asynctasks.vim or asyncrun.vim. To use it, try the following code in your vimrc.

function! s:run_in_floaterm(opts)
  execute 'FloatermNew --position=bottomright' .
                   \ ' --wintype=float' .
                   \ ' --height=0.4' .
                   \ ' --width=0.4' .
                   \ ' --title=floaterm_runner' .
                   \ ' --autoclose=0' .
                   \ ' --silent=' . get(a:opts, 'silent', 0)
                   \ ' --cwd=' . a:opts.cwd
                   \ ' ' . a:opts.cmd
  " Do not focus on floaterm window, and close it once cursor moves
  " If you want to jump to the floaterm window, use <C-w>p
  " You can choose whether to use the following code or not
  stopinsert | noa wincmd p
  augroup close-floaterm-runner
    autocmd!
    autocmd CursorMoved,InsertEnter * ++nested
          \ call timer_start(100, { -> s:close_floaterm_runner() })
  augroup END
endfunction
function! s:close_floaterm_runner() abort
  if &ft == 'floaterm' | return | endif
  for b in tabpagebuflist()
    if getbufvar(b, '&ft') == 'floaterm' &&
          \ getbufvar(b, 'floaterm_jobexists') == v:false
      execute b 'bwipeout!'
      break
    endif
  endfor
  autocmd! close-floaterm-runner
endfunction
let g:asyncrun_runner = get(g:, 'asyncrun_runner', {})
let g:asyncrun_runner.floaterm = function('s:run_in_floaterm')
let g:asynctasks_term_pos = 'floaterm'

Then your task will be run in the floaterm instance. See asynctasks.vim Wiki for more information.

You can also modify the code in s: run_in_floaterm by yourself to meet your tastes, which is the reason why this code is not made builtin.

The wrapper script must be located in autoload/floaterm/wrapper/ directory, e.g., autoload/floaterm/wrapper/fzf.vim.

There are two ways for a command to be spawned:

• To be executed after spawning $SHELL. Here is the old implementation of fzf wrapper

  function! floaterm#wrapper#fzf#() abort
    return ['floaterm $(fzf)', {}, v:true]
  endfunction

  The code above returns a list. floaterm $(fzf) is the command to be executed. v:true means the command will be executed after the &shell startup. In this way, the second element of the list must be {}.

• To be executed through termopen()/term_start() function, in that case, a callback option can be provided. See fzf wrapper

  function! floaterm#wrapper#fzf#(cmd) abort
    let s:fzf_tmpfile = tempname()
    let cmd = a:cmd . ' > ' . s:fzf_tmpfile
    return [cmd, {'on_exit': funcref('s:fzf_callback')}, v:false]
  endfunction

  function! s:fzf_callback(...) abort
    if filereadable(s:fzf_tmpfile)
      let filenames = readfile(s:fzf_tmpfile)
      if !empty(filenames)
        if has('nvim')
          call floaterm#window#hide(bufnr('%'))
        endif
        for filename in filenames
          execute g:floaterm_open_command . ' ' . fnameescape(filename)
        endfor
      endif
    endif
  endfunction

  In the example above, after executing :FloatermNew fzf, function floaterm#wrapper#fzf# will return ['fzf > /tmp/atmpfilename', {'on_exit': funcref('s:fzf_callback')}, v:false].

  Here v:false means cmd(fzf > /tmp/atmpfilename) will be passed through termopen()(neovim) or term_start()(vim). As a result, an fzf interactive will be opened in a floaterm window. After choosing a file using <CR>, fzf exits and the filepath will be written in /tmp/atmpfilename. Then the function s:fzf_callback() will be invoked to open the file.

Function floaterm#buflist#gather() returns a list contains all the floaterm buffers.

Function floaterm#terminal#open_existing({bufnr}) opens the floaterm whose buffer number is {bufnr}.

For reference, see floaterm source for vim-clap.

https://github.com/voldikss/vim-floaterm/wiki

https://github.com/voldikss/vim-floaterm/issues?q=label%3AFAQ

https://github.com/voldikss/vim-floaterm/issues?q=label%3A%22breaking+change%22

• vim-floaterm-repl
• coc-floaterm
• fzf-floaterm
• popc-floaterm
• Leaderf-floaterm

• Vim and Neovim the editor God

• floaterm executable is modified from vim-terminal-help

• Some features require neovim-remote

MIT
